GeoVision FD5300 User Manual
Page 2
Dimensions
Hard‐Ceiling Mount
In‐Ceiling Mount
Specifications
Camera
Image Sensor
1/2.5” progressive scan CMOS
Picture Elements
2560 (H) x 1920 (V)
Color
0.15 Lux
B/W
0.10 Lux
Minimum
Illumination
IR ON
0 Lux
Shutter Speed
Automatic, Manual (1/5 ~ 1/8000 sec.)
White Balance
Automatic, Manual (2800K ~ 8500K)
Gain Control
Automatic
S/N Ratio
45 dB
BLC
Yes
Lens
Megapixel
Yes
Day/Night
Yes (with removable IR‐cut filter)
Lens Type
Varifocal
Focal Length
4.5 ~ 10 mm
Maximum Aperture
F/1.6
Mount
CS Mount
Image Format
1/2.5”
Horizontal FOV
70°~34°
Focus
Manual (w/lock)
Zoom
Manual (w/lock)
Operation
Iris
Manual (w/lock)
Max. Torque (Focus/ Zoom Screws)
0.049 N.m
IR LED Quantity
10 IR LEDs
Max. IR Distance
15 m (50 ft.)
Operation
Video Compression
H.264, MJPEG
Video Streaming
Dual streams from H.264 and MJPEG
Frame Rate
10 fps at 2560 x 1920
* The frame rate and the performance may vary depending on the number of connections and data
bitrates (different scenes).
Image Setting
Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker‐less, Image Orientation, Shutter Speed,
Backlight Compensation, D/N Sensitivity, WDR, Defog
GV-FD5300
March
6,
2014
