Name
Details
Model No.
Pole Mount Bracket Kit
(Ø 4" ~ 6")
Dimensions
Bracket: 241 x 161 mm (9.5’’ x 6.3”)
Weight: 1.70 Kg ( 3.75 lb)
Steel Strap Diameter: Ø 4" ~ 6"
GV‐Mount400
Pole Mount Bracket Kit
(Ø 6" ~ 7.5")
Dimensions
Bracket: 241 x 161 mm (9.5’’ x 6.3”)
Weight: 1.70 Kg (3.75 lb)
Steel Strap Diameter: Ø 6" ~ 7.5"
GV‐Mount410
Extension Tube
Four options are available.
Dimensions:
Ø 5.4 x 10 or 20 or 30 or 50 cm
(Ø 2.1’’ x 3.9’’ or 7.9’’ or 11.8’’ or 19.7”)
Weight:
180 g or 390 g or 550 g or 800 g
(0.4 lb or 0.86 lb or 1.21lb or 1.76 lb)
GV‐Mount702
Wall Mount Bracket
Dimensions: 154 x 108 x 50 mm (6.1’’ x 4.3’’ x 2”)
Weight: 240 g (0.53 lb)
GV‐Mount900
GV‐VD Series Dome
Housing
Dimensions: Ø 186 x 97.5 mm (Ø 7.3’’ x 3.8”)
Weight: 600 g (1.32 lb)
GV‐Mount901
Wall Mount Bracket
Dimensions: 170 x 150 x 110 mm (6.7’’ x 5.9” x 4.3’’)
Weight: 610 g (1.34 lb)
GV‐Mount909
Power over Ethernet (PoE)
Adapter
The GV‐PA191 is a Power over Ethernet (PoE) adapter
designed to provide power to the IP device through a
single Ethernet cable.
GV‐Relay V2
The GV‐Relay V2 is designed to expand the voltage load of
GV IP devices. It provides 4 relay outputs, and each can be
set as normally open (NO) or normally closed (NC)
independently as per your requirement.
