GeoVision VD2440-E - Manual

GV-VD2440-E 2MP H.264 3x zoom WDR Pro IR Arctic Vandal Proof IP Dome
•
1/3.2” progressive scan CMOS
•
Dual streams from H.264 and MJPEG
•
Up to 30 fps at 1920 x 1080
•
Vandal resistance ( IK10+ )
•
Ingress protection ( IP67 )
•
Wide temperature tolerance (‐40°C ~ 50°C / ‐40°F ~ 122°F)
•
Motorized varifocal lens for remote focus/zoom adjustment
•
3‐axis mechanism (pan / tilt / roll)
•
Removable IR‐cut filter for Day/Night function
•
High power IR LEDs
•
Intelligent IR
•
IR distance up to 20 m (65.6 ft.)
•
External microphone
•
2‐way audio
•
One sensor input and alarm output
•
TV‐out support
•
Built‐in micro SD card slot (SD/SDHC) for local storage
•
DC12V / AC24V / PoE
•
Wide Dynamic Range Pro (WDR Pro)
•
Defog
•
Motion detection
•
Tampering alarm
•
Privacy mask
•
IP address filtering
•
Supports iPhone, iPad, Android & 3GPP
•
31 languages on Web interface
•
ONVIF (Profile S) conformant
*No Memory card slot & local storage function for Argentina.
Active Tampering Alarm
Tampered Focus Change Camera Shift
Introduction
GV‐VD2440‐E is an outdoor camera designed with IK10+ vandal resistance, IP67 ingress protection and tolerance to extreme
temperatures. With its motorized varifocal lens, the user can zoom and focus the camera from the Web interface. The camera is
equipped with a WDR Pro with which the camera can process scenes containing contrasting intensity of lights and produce clear
images. This night vision is enhanced with its high power LEDs with up to 20 m (65.6 ft.) effective distance.
GV-VD2440-E March 6, 2014
- 1 -
