GeoVision VD2540-E - Manual

GV-VD2540-E 2MP H.264 3x zoom Super Low Lux WDR IR Arctic Vandal Proof IP
Dome
•
1/2.8" progressive scan super low lux CMOS
•
Min. illumination at 0.02 lux
•
Dual streams from H.264 and MJPEG
•
Up to 30 fps at 1920 x 1080
•
Vandal resistance ( IK10+ )
•
Ingress protection ( IP67 )
•
Wide temperature tolerance (‐40°C ~ 50°C / ‐40°F ~ 122°F)
•
Motorized varifocal lens for remote focus/zoom adjustment
•
3‐axis mechanism (pan / tilt / roll)
•
Removable IR‐cut filter for Day/Night function
•
High power IR LEDs
•
Intelligent IR
•
IR distance up to 25 m (82 ft.)
•
External microphone
•
2‐way audio
•
One sensor input and alarm output
•
TV‐out support
•
Built‐in micro SD card slot (SD/SDHC) for local storage
•
DC12V / AC24V / PoE
•
Wide Dynamic Range (WDR)
•
3D DNR (Digital Noise Reduction)
•
Defog
•
Motion detection
•
Tampering alarm
•
Privacy mask
•
IP address filtering
•
Supports iPhone, iPad, Android & 3GPP
•
31 languages on Web interface
•
ONVIF (Profile S) conformant
*No Memory card slot & local storage function for Argentina.
Active Tampering Alarm
Tampered Focus Change Camera Shift
Introduction
GV‐VD2540‐E is an outdoor camera designed with IK10+ vandal resistance, IP67 ingress protection and tolerance to extreme
temperatures. With its motorized varifocal lens, the user can zoom and focus the camera from the Web interface. The camera is
equipped with a super low lux CMOS image sensor with which the camera is capable of providing a color live view in near darkness.
This night vision is further enhanced with its high power LEDs with up to 25 m (82 ft.) effective distance.
GV-VD2540-E March 6, 2014
- 1 -
