GV-VD5340

5MP H.264 3x zoom WDR IR Vandal Proof IP Dome



1/2.5” progressive scan CMOS

Dual streams from H.264 and MJPEG

Up to 10 fps at 2560 x 1920

Vandal resistance (

IK10+

)

Ingress protection (

IP67

Motorized varifocal lens for remote focus/zoom adjustment

3‐axis mechanism (pan / tilt / roll)

Removable IR‐cut filter for Day/Night function

High power IR LEDs

Intelligent IR

IR distance up to 20 m (65.6 ft.)

External microphone

2‐way audio

One sensor input and alarm output

TV‐out support

Built‐in micro SD card slot (SD/SDHC) for local storage

DC12V / AC24V / PoE

Wide Dynamic Range (WDR)

Defog

Motion detection

Tampering alarm

Privacy mask

IP address filtering

Supports iPhone, iPad, Android & 3GPP

31 languages on Web interface

ONVIF (Profile S) conformant

*No Memory card slot & local storage function for Argentina.



Active Tampering Alarm

Tampered

Focus Change

Camera Shift



Introduction

GV‐VD5340 is an outdoor camera designed with

IK10+

 vandal resistance and

IP67

 ingress protection. With its motorized varifocal

lens, the user can zoom and focus the camera from the Web interface. This night vision is enhanced with its high power LEDs with
up to 20 m (65.6 ft.) effective distance.

GV-VD5340

March

6,

2014
