Specifications
Camera
GV‐UBL2401‐0F
GV‐UBL2401‐1F
GV‐UBL2401‐2F
GV‐UBL2401‐3F
Image Sensor
1/3.2” progressive scan CMOS ”
Picture Elements
1920 (H) x 1080 (V)
Color
0.08 Lux
B/W
0.05 Lux
Minimum
Illumination
IR ON
0 Lux
Shutter Speed
Automatic, Manual (1/5 ~ 1/8000 sec.)
White Balance
Automatic, Manual (2800K ~ 8500K)
Gain Control
Automatic
S/N Ratio
47 dB
BLC
Yes
WDR Pro
Yes (with WDR sensor)
Lens
GV‐UBL2401‐0F
GV‐UBL2401‐1F
GV‐UBL2401‐2F
GV‐UBL2401‐3F
Megapixel
Yes
Focal Length
3 mm
4 mm
8mm
12 mm
Day/Night
Yes (with removable IR‐cut filter)
Lens Type
Fixed Lens
Maximum Aperture
F/2.0
F/1.5
F/1.6
Mount
M12
Image Format
1/3”
Horizontal FOV
80°
58°
31°
20°
Focus
Fixed
Zoom
Fixed
Operation
Iris
Fixed
IR LED Quantity
4 IR LEDs
Max. IR Distance
10 m (32.81 ft.)
Operation
Video Compression
H.264, MJPEG
Video Stream
Dual streams from H.264 and MJPEG
Frame Rate
30 fps at 1920 x 1080
*The frame rate and the performance may vary depending on the number of connections and data
bitrates (different scenes).
Image Setting
Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker‐less, Image Orientation, Backlight
Compensation, Zoom, Focus Change, Shutter Speed, D/N Sensitivity, WDR, Defog
Audio Support
No
Video Resolution
4 : 3
1600 x 1200, 1280 x 960, 640 x 480, 320 x 240
16 : 9
1920 x 1080, 1280 x 720, 640 x 360, 448 x 252
Main Stream
5 : 4
1280 x 1024, 640 x 512, 320 x 256
4 : 3
640 x 480, 320 x 240
16 : 9
640 x 360, 448 x 252
Sub Stream
5 : 4
640 x 512, 320 x 256
Network
Interface
10/100 Ethernet
Protocol
HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS
(DSCP), ONVIF (Profile S)
Mechanical
Temperature Detector
Yes
Power
2‐pin terminal block, PoE
Ethernet
Ethernet (10/100 Base‐T), RJ‐45 cable
Two types of models for selection: Waterproof or Non‐Waterproof with smaller size
Digital I/O
I/O Wire
Connectors
Local Storage
Micro SD card slot (SD/SDHC, SD version 2.0 only, Class 10)
* SDXC and UHS‐I card types are not supported.
General
Start‐up
Environment
Temperature
Operation
‐20°C ~ 45°C (‐4°F ~ 113°F)
Humidity
10% to 90% (no condensation)
Power Source
5V DC / PoE
Max. Power Consumption
5.52 W
Dimensions
124 x 65 x 69 mm (4.8” x 2.6” x 2.7”)
