Dimensions
Specifications
Camera
Image Sensor
1/3” progressive scan CMOS ”
Picture Elements
1280 (H) x 1024 (V)
Color
0.05 Lux
B/W
0.03 Lux
Minimum
Illumination
IR ON
0 Lux
Shutter Speed
Automatic, Manual (1/5 ~ 1/8000 sec.)
White Balance
Automatic, Manual (2800K ~ 8500K)
Gain Control
Automatic
S/N Ratio
50 dB
BLC
Yes
Lens
Megapixel
Yes
Focal Length
3 ~ 9 mm
Day/Night
Yes (with removable IR‐cut filter)
Lens Type
Motorized varifocal lens
Maximum Aperture
F/1.2
Mount
Ø 14 mm
Image Format
1/2.7”
Horizontal FOV
86°~32°
Focus
Auto Focus
Zoom
3X Optical Zoom
Operation
Iris
DC Drive
Max. Torque (Focus/ Zoom Screws)
0.049 N.m
IR LED Quantity
16 IR LEDs
Max. IR Distance
40 m (131 ft.)
Operation
Video Compression
H.264, MJPEG
Video Stream
Dual streams from H.264 or MJPEG
Frame Rate
30 fps at 1280 x 1024
* The frame rate and the performance may vary depending on the number of connections and data
bitrates (different scenes).
Image Setting
Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker‐less, Image Orientation,
Shutter Speed, D/N Sensitivity, Backlight Compensation, WDR, Defog, Zoom, Focus Change
Audio Compression
G.711, AAC (optional)
Audio Support
Two‐Way Audio
Sensor Input
1 Input (Dry Contact)
Alarm Output
1 Digital Output (200mA 5V DC)
Video Resolution
4 : 3
1280 x 960, 640 x 480, 320 x 240
16 : 9
1280 x 720, 640 x 360, 448 x 252
Main Stream
5 : 4
1280 x 1024, 640 x 512, 320 x 256
GV-BL1210
March
6,
2014
