Dimensions
Specifications
Camera GV‐MFD2501‐0F GV‐MFD2501‐1F GV‐MFD2501‐2F GV‐MFD2501‐3F GV‐MFD2501‐4F
Image Sensor 1/2.8" progressive scan super low lux CMOS
Picture Elements 1920 (H) x 1080 (V)
Minimum Illumination
Color
B/W
0.02 Lux
Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec.)
White Balance Automatic, Manual (2800K ~ 8500K)
Gain Control Automatic
S/N Ratio 52 dB
WDR Yes
Lens
Megapixel Yes
Day/Night Yes (Electronic)
Iris Fixed
Focal Length 3 mm 4 mm 8 mm 12 mm 2.1 mm
Maximum Aperture F/2.0 F/1.5 F/1.6 F/1.6 F/1.8
Mount M12, Pitch 0.5 mm
Image Format 1/3"
Horizontal FOV 102° 72° 38° 25° 150°
Focus Fixed
Zoom Fixed Operation
Iris Fixed
Operation
Video Compression H.264, MJPEG
Video Streaming Dual streams from H.264 and MJPEG
Frame Rate
30 fps at 1920 x 1080
* The frame rate and the performance may vary depending on the number of connections and data bitrates
(different scenes).
Image Setting
Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker‐less 50/60 Hz, Image Orientation, Shutter
Speed, Backlight Compensation , WDR , Defog, Super Low Lux
Audio Compression G.711, AAC (optional)
Audio Support Two‐Way Audio
Sensor Input No
Alarm Output No
Video Resolution
4:3 1280 x 960, 640 x 480, 320 x 240
16:9 1920 x 1080, 1280 x 720, 640 x 360, 448 x 252 Main Stream
5:4 1280 x 1024, 640 x 512, 320 x 256
4:3 640 x 480, 320 x 240
16:9 640 x 360, 448 x 252 Sub Stream
5:4 640 x 512, 320 x 256
GV-MFD2501 Series March 6, 2014
- 2 -
