GeoVision UBX3301 Series User Manual
Page 2

Dimensions
Specifications
Camera
GV‐UBX3301‐0F
GV‐UBX3301‐1F
GV‐UBX3301‐2F
Image Sensor
1/2.5” progressive scan CMOS ”
Picture Elements
2048 (H) x 1536 (V)
Color
0.15 Lux
B/W
0.10 Lux
Minimum
Illumination
IR ON
0 Lux
Shutter Speed
Automatic, Manual (1/5 ~ 1/8000 sec)
White Balance
Automatic, Manual (2800K ~ 8500K)
Gain Control
Automatic
S/N Ratio
50 dB
BLC
Yes
Lens
Megapixel
Yes
Focal Length
3 mm
4 mm
8 mm
Day/Night
Yes (with removable IR‐cut filter)
Lens Type
Fixed
Maximum Aperture
F/1.6
Mount
M12, Pitch 0.5 mm
Image Format
1/3”
Horizontal FOV
87°
62°
33°
Focus
Zoom
Operation
Iris
Fixed
IR LED Quantity
4 IR LEDs
Max. IR Distance
10 m (32.81 ft.)
Operation
Video Compression
H.264, MJPEG
Video Stream
Dual streams from H.264 and MJPEG
Frame Rate
20 fps at 2048 x 1536
*The frame rate and the performance may vary depending on the number of connections and data bitrates
(different scenes).
Image Setting
Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker‐less, Image Orientation, Shutter
Speed, D/N Sensitivity, Backlight Compensation, WDR, Defog
Audio Compression
G.711, AAC (optional)
Audio Support
Two‐Way Audio
Video Resolution
4 : 3
2048 x 1536, 1600 x 1200, 1280 x 960, 640 x 480, 320 x 240
16 : 9
1920 x 1080, 1280 x 720, 640 x 360, 448 x 252
Main Stream
5 : 4
1280 x 1024, 640 x 512, 320 x 256
4 : 3
640 x 480, 320 x 240
16 : 9
640 x 360, 448 x 252
Sub Stream
5 : 4
640 x 512, 320 x 256
Network
Interface
10/100 Ethernet
Protocol
HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP),
ONVIF (Profile S)
GV-UBX3301
Series
March
6,
2014
- 2 -
