Dimensions
Specifications
Camera GV‐EFD1100‐0F (Coming) GV‐EFD1100‐1F
Image Sensor 1/3" progressive scan low lux CMOS
Picture Elements 1280 (H) x 1024 (V)
Color 0.05 Lux
B/W 0.03 Lux
Minimum
Illumination
IR ON 0 Lux
Shutter Speed Automatic, Manual (1/5 ~ 1/8000 sec.)
White Balance Automatic, Manual (2800K ~ 8500K)
Gain Control Automatic
S/N Ratio 50 dB
WDR Yes
Lens
Megapixel Yes
Day/Night Yes (with removable IR‐cut filter)
Focal Length 2.8 mm 3.6 mm
Lens Type Fixed
Maximum Aperture F/1.8
Mount M12, Pitch 0.5 mm
Horizontal FOV 93° 72°
Image Format 1/2.7"
Focus Fixed
Zoom Fixed Operation
Iris Fixed
IR LED Quantity 12 IR LEDs
Max. IR Distance 15 m (50 ft.)
Operation
Video Compression H.264, MJPEG
Video Streaming Dual streams from H.264 and MJPEG
Frame Rate
30 fps at 1280 x 1024
* The frame rate and the performance may vary depending on the number of connections
and data bitrates (different scenes).
Image Setting
Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker‐less, Image
Orientation, Shutter Speed, D/N Sensitivity, Backlight Compensation, WDR, Defog
Audio Compression G.711, AAC (Optional)
Audio Support One‐way Audio
Video Resolution
4:3 1280 x 960, 640 x 480, 320 x 240
16:9 1280 x 720, 640 x 360, 448 x 252 Main Stream
5:4 1280 x 1024, 640 x 512, 320 x 256
4:3 640 x 480, 320 x 240
16:9 640 x 360, 448 x 252 Sub Stream
5:4 640 x 512, 320 x 256
