18
Video card: 64 MB or higher
Supported OS: Windows 98/ME/2000/XP/Vista/7/8
Supported browsers: IE6.0-10.0, Firefox, Safari, Google Chrome
Supported mobile OS: iOS 4.3 and higher / Android 2.1 and higher
Certification: CE, FCC, RoHS, R&TTE
Warranty: Limited 3-year warranty
3.2. Main component parts
1
1. 3 assembly screws and plugs
2. C803IP.2 camera
3. Camera base
4. Software CD-ROM
5. User's manual
6. DC supply
7. Ethernet cable
3.3. Connections
2
1. Ethernet port
2. DC connection
3. Reset button
4. Camera installation
4.1. Connecting the camera
• Connect the adapter cable to the DC connection of the camera 3 . Then insert the
adapter plug into the power outlet.
• Connect the included ethernet cable to the network port of the camera 4 . Connect
the other end of the ethernet cable to your router. The green LED on the ethernet port
will light up when the camera is connected to the network.
You can now operate your IP Camera using your smartphone or PC. Go to section 4.2 for
use with smartphone and go to section 4.3 for installation on your PC.
4.2. Settings for smartphone use
! Attention! To use the “ELRO INSTALL” App, you need a smartphone with internet
access.
! Attention! To scan a QR code, you need an APP that can scan barcodes.
To set up your camera using Android, go to section 4.2.1. To set up your camera using iOS,
go to section 4.2.2.
4.2.1. Android
• Download the App: “Elro Install” via Google Play and install it.
• Start the App. The start screen of the app appears. L
• Press the “Click here to add camera” option. The “Add camera” menu appears. M
• Press the “Scan” button. M1 Next, scan the QR code on the bottom of your camera. You
can also choose to manually enter the code behind “UID”.
M2
You can find this code
under the QR code on your IP camera.
• Next, enter the code: 000000 after “Security code”. M3
