ELRO C904IP.2 Plug & play network camera - Manual (Page 19)

19
Minimal system requirements:
CPU: 2.0 GHZ or higher
Memory: 256 MB or higher
Video card: 64 MB or higher
Supported OS: Windows 98/ME/2000/XP/Vista/7/8
Supported browsers: IE6.0-10.0, Firefox, Safari, Google Chrome
Supported mobile OS: iOS 4.3 and higher / Android 2.1 and higher
Certification: CE, FCC, RoHS, R&TTE
Warranty: Limited 3-year warranty
3.2. Main component parts
1
1. Software CD-ROM
2. Removable antenna
3. 4 assembly screws and plugs
4. User's manual
5. Ethernet cable
6. C904IP.2 camera
7. DC supply
3.3. Connections
2
1. Antenna port
2. DC connection
3. Audio jack (output)
4. Ethernet port
5. I/O port
6. Audio jack (input)
7. Reset button
4. Camera installation
4.1. Connecting the camera
• Unscrew the dome of the camera 3 . Next, remove the packaging material 4 and
screw the dome back on.
• Screw the antenna into the antenna port 5 .
• Connect the adapter cable to the DC connection of the camera 6 . Then insert the
adapter plug into the power outlet.
• Connect the included ethernet cable to the network port of the camera 7 . Connect
the other end of the ethernet cable to your router. The green LED on the ethernet port
will light up when the camera is connected to the network.
You can now operate your IP Camera using your smartphone or PC. Go to section 4.2 for
use with smartphone and go to section 4.3 for installation on your PC.
