Getting started
2
1. Plug the small end
of the smaller power
adapter into the jack
on the underside of the
charger, then route the
cord through the slot as
shown.
2. Plug the
large end of
the smaller
power adapter
into an
electrical
outlet.
Charger installation
NOTES:
1. Use only the power adapter supplied with this product or equivalent.
2. This power unit is intended to be correctly oriented in a vertical or floor mount
position. The prongs are not designed to hold the plug in place if it is plugged
into a ceiling or an under-the-table/cabinet outlet.
Install the charger as shown below. Make sure that the electrical
outlet is not controlled by a wall switch.
