23
J-F SERIES PARTS LIST
Pump Model J08F J15F J15HF J22F J22HF J37F J37HF J55CF J55CHF J75CF J75CHF
Pos. No. Part Description Item # Item # Item # Item # Item # Item # Item # Item # Item # Item # Item #
01 Strainer with Bottom Plate - - - 201973 201973 201973 201973 201976 201976 201976 201976
01 Strainer 201969 201969 201969 - - - - - - - -
01-2 Bottom Plate 202007 202007 202007 - - - - - - - -
02 Suction Cover 202026 202026 202026 202009 202011 202009 202011 202031 202032 202031 202032
03 Impeller Nut 202894 202894 202894 202894 202894 202894 202894 202895 202895 202895 202895
04 Lock washer 202907 202907 202907 202907 202907 202907 202907 202904 202904 202904 202904
05 Impeller 202933 202067 202069 202937 202072 202074 202076 202078 202079 202082 202083
06 Impeller Key 202140 202140 202140 202140 202140 202140 202140 202141 202141 202141 202141
07 Pump Housing 202163 202165 202163 202167 202167 202167 202167 203007 203007 203007 203007
07 -1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
08 Oil Chamber Cover 202211 202211 202211 202211 202211 202211 202211 203043 203043 203043 203043
08 -1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
09 Lip Seal FKM 202233 202233 202233 202233 202233 202233 202233 203058 203058 203058 203058
09A Double Lip Seal FKM - - - - - - - 202240 202240 202240 202240
10 Shaft Sleeve - - - - - - - 202256 202256 202256 202256
10-1 O-Ring (Kit Only) - - - - - - - Kit Kit Kit Kit
10-2 O-Ring (Kit Only) - - - - - - - Kit Kit Kit Kit
13 Mechanical Seal FKM** 200500 200500 200500 200500 200500 200500 200500 200304 200304 300304 300304
14 Lower Ball Bearing 200958 200958 200958 200959 200959 200959 200959 200960 200960 200961 200961
14-1 Lower Ball Bearing - - - - - - - 200960 200960 200961 200961
14-2 Lower Bearing Retainer Clip - - - - - - - 202279 202279 202279 202279
17 Rotor w/ Shaft, 3 PH 204015 204016 204016 204017 204017 204018 204018 204019 204019 204020 204020
18 Stator w/Casing, 208V, 3PH 200525 200529 200529 200533 200533 200537 200537 200666 200666 - -
18 Stator w/Casing, 230/460V, 3PH 200547 200551 200551 200555 200555 200559 200559 200563 200563 200567 200567
18 Stator w/Casing, 575V, 3PH 200589 200593 200593 200597 200597 200601 200601 200606 200606 200610 200610
19 Wire Connection Kit* 204202 204202 204202 204203 204203 204203 204203 204203 204203 204203 204203
20 Upper Ball Bearing 200967 200967 200967 200958 200958 200958 200958 200959 200959 200959 200959
20-1 O-Ring (Kit Only) - - - - - - - Kit Kit Kit Kit
21A Oil Chamber - - - - - - - 202178 202178 202169 202169
21A-1 O-Ring (Kit Only) - - - - - - - Kit Kit Kit Kit
26 Pump Top Cover 202435 202435 202435 202445 202445 202445 202445 202439 202439 202439 202439
26-1 O-Ring (Kit Only) Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit Kit
27 Power Cable w/ Gland- 3PH (High-Temp) 201733 201733 201733 203776 203776 203776 203776 203776 203776 203776 203776
