MS-1 SPECIFICATIONS
Message Server 1 SPECIFICATIONS
Connection:
RJ45 with shielded Ethernet/PoE
cable (CAT5, CAT5e, CAT6 or CAT7)
Weight:
12 lbs. (5.4 kg)
Power Consumption
(100~240VAC 50/60Hz):
< 350 watts
Ambient Operating
Temperature Range:
32-113 degrees F (0-45 degrees C)
Dimensions:
Height:
Width:
Depth:
0.75 inches (44.5mm)
19 inches (483mm)
17.5 inches (444 mm)
Compliance:
RoHS directive
UL listed, CE marked
Message Server 1 Block Diagram
RS-232
USB
VGA
LED
ID Switches
Storage
Drive
Control
Vocia
CobraNet
VoIP
HostProcessor
