fr12spa1.5sm-rev0913 Model FR12SPA1.5 Design Level 3 Page 3
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
1 FS001182-000 Screw, Self-Tapping 2
2 MF001164-000 Cover, Motor 1
3 FS001183-000 Hex Nut 1
4 MF001165-000 Handle 1
5 FS001184-000 Nut, Gland 2
6 MF001166-000 Spacer, Gland 2
7 SL001167-000 Ring, Sealing 2
8 FS001185-000 Hex Nut 4
9 FS001186-000 Lock Washer 4
10 FS001187-000 Stud 4
11 EL001171-000 Circuit Breaker 1
12 FS001188-000 Capscrew, Hex Head 4
13 FS001189-000 Lock Washer 8
14 SL001168-000 Gasket, Casing 1
15 FS001190-000 Capscrew, Hex Head 4
16 MF001173-000 Impeller 1
17 MF001174-000 Shim As. Req.*
18 MF001175-000 Cover, Suction 1
19 MF001176-000 Plate, Strainer 1
20 MF001177-000 Screen, Strainer 1
21 MF001178-000 Casing, Volute, 1½ NPT 1
MF001179-000 Casing, Volute, 1½ BSPT (tapered) 1
22 SL001169-000 O-Ring 2
23 SL001170-000 Seal 1
24 MF001180-000 Tube, Casing 1
25 EL001193-000 Motor 1
26 EL001194-000 Clamp, Cable 1
27 FS001191-000 Screw, Machine 1
28 EL001195-000 Power Cable Assembly Complete 1
29 FS001192-000 Washer, Lock 1
30 MF001181-000 Lug, Compression 1
31 EL001196-000 Nut, Insulated Wire 1
* Typically 1
SERVICE AND OPERATING MANUAL
Model FR12SPA1.5 Portable
Submersible Dewatering Pump
Design Level 3
