EBARA Fluid Handling 23
PARTS LIST
Pump Model EFQT-12
ITEM NO. PART NAME QTY PART NUMBER
01 PUMP CASING 01
02 * IMPELLER 01
03 * SEAL ASSY 01
04 * VICTAULIC CPLG 01
05 ACCESS COVER ASSY 01
06 * COVER GSTK 01
07 COVER CLAMP 02
08 MACHINE BOLT 04
09 CLAMP BAR SCREW 02
10 * WEAR PLT ADJ SCREW 04
11 * WEAR PLT JAM NUT 04
12 PIPE PLUG 01
13 HEX HD CAPSCREW 12
14 LOCKWASHER 12
15 HEX NUT 12
16 DISCH ADAPTOR 01
17 ACCESSORY PLUG 01
18 * OIL SEAL 01
19 * DISCH FLANGE GSKT 01
20 PIPE PLUG 01
21 * WEAR PLT O-RING 01
22 * CASING O-RING 01
23 HEX HD CAPSCREW 02
24 LOCKWASHER 02
25 * SEAL CAVITY VENT 01
26 * PEDESTAL VENT 01
27 * WAVE WASHER 02
28 * OIL SEAL 01
29 * SHAFT KEY 01
30 * IMP SHAFT 01
31 BEARING CAP 01
32 * BALL BEARING 01
33 * BRG CAP O-RING 01
34 HEX HD CAPSCREW 06
35 LOCKWASHER 06
36 OIL SIGHT GAUGE 01
37 PIPE PLUG 01
38 PED DRAIN PLUG 01
39 BEARING HOUSE 01
40 * BALL BEARING 01
41 HEX HD CAPSCREW 20
42 LOCKWASHER 20
43 * PEDESTAL O-RING 01
44 SEAL PLATE 01
45 CASING DRAIN PLUG 01
46 PEDESTAL FOOT 01
47 STUD 04
48 LOCKWASHER 04
49 HEX NUT 04
50 STUD 04
* INDICATES PARTS RECOMMENDED FOR STOCK
