Ebara Submersible Sewage Pumps DVFU / DVFMU
Operating, Installation, and Maintenance
Ebara Fluid Handling
www.pumpsebara.com 5
(803) 327-5005 • (803) 327-5097 (fax) rev. 10/11
Installation
3. Electrical Wiring:
(1) Wiring
a) Wire as indicated for the appropriate start system as shown in Fig. 3.
b) Loose connections will stop the pump. Make sure all electrical connections are secure.
output 2 to 10HP
208/230V
460V
output 15 to 30HP
208/230V
460V
warning
Check that the power is locked off and disconnected before working on pump. all electrical work should be
performed by a qualified electrician and all national and local electrical codes must be observed.
G – GRN
L1 – RED – T1 – T7
L2 – WHT – T2 – T8
L3 – BLK – T3 – T9
T4 – T5 – T6 – T10 – T11 – T12
P1 – RED
P2 – WHT
P3 – BLK
P4 – OR
G – GRN
G – GRN
L1 – RED – T1 – T12
L2 – WHT – T2 – T10
L3 – BLK – T3 – T11
T4 – T7
T5 – T8
T6 – T9
P1 – RED
P2 – WHT
P3 – BLK
P4 – ORG
G – GRN G – GRN
L
1
– RED – T
1
– T
7
– T
6
– T
12
L
2
– WHT – T
4
– T
8
– T
2
– T
10
L
3
– BLK – T
3
– T
9
– T
5
– T
11
P
1
– RED
P
2
– WHT
P
3
– BLK
P
4
– ORG
G – GRN
G – GRN
L1 – RED – T1
L2 – WHT – T2
L3 – BLK – T3
T4 – T7
T5 – T8
T6 – T9
T10 – T11 – T12
P1 – RED
P2 – WHT
P3 – BLK
P4 – ORG
G – GRN
