Ebara Submersible Sewage Pumps DVFU / DVFMU
Operating, Installation, and Maintenance
Ebara Fluid Handling
www.pumpsebara.com 10
(803) 327-5005 • (803) 327-5097 (fax) rev. 10/11
7 1 /
2
to 10HP
924
2
838
2
115
5
120
4
115
3
120
3
120
2
115
2
115
1
193
1
849
1
193
2
115
4
849
2
811
1
120
6
838
1
924
1
811
2
909
802
801
816
817
021
080
001
039
005
114
125
111
117
876
814
830
PART
NO.
001
005
021
039
080
†111
†114
†115-1
†115-2
†115-3
†115-4
†115-5
†117
120-1
120-2
120-3
120-4
120-5
120-6
125
PART NAME
CASING
INTERMEDIATE CASING
IMPELLER
KEY
BUSHING
MECHANICAL SEAL
OIL SEAL
O-RING
O-RING
O-RING
O-RING
O-RING
GASKET
BOLT
BOLT
BOLT
BOLT
BOLT
BOLT
BOLT
MATERIAL
CAST IRON
CAST IRON
CAST IRON
420 STAINLESS
STEEL
—
RUBBER (NBR)
RUBBER (NBR)
RUBBER (NBR)
RUBBER (NBR)
RUBBER (NBR)
RUBBER (NBR)
304 STAINLESS
304 STAINLESS
304 STAINLESS
304 STAINLESS
304 STAINLESS
304 STAINLESS
304 STAINLESS
ASTM, AISI
CODE
A48 Class 30
A48 Class 30
A48 Class 30
AISI420
A283 Grade D
AISI304
AISI304
AISI304
AISI304
AISI304
AISI304
AISI304
NO. FOR
1 UNIT
1
1
1
1
1
1 SET
1
1
1
1
1
1
1
8
4
6
3
4
2
1
PART
NO.
174
193-1
193-2
200
801
802
811-1
811-2
814
816
817
830
838-1
838-2
†849-1
†849-2
876
909
924-1
924-2
PART NAME
DISCHARGE ELBOW
PLUG
PLUG
LIFTING HANGER
ROTOR
STATOR
POWER CABLE
CONTROL CABLE
MOTOR COVER
BRACKET
BRACKET
SHAFT
WASHER
WASHER
BALL BEARING
BALL BEARING
MOTOR PROTECTOR
LEAKAGE DETECTOR
PACKING
PACKING
MATERIAL
CAST IRON
304 STAINLESS
304 STAINLESS
STEEL
—
—
—
—
CAST IRON
CAST IRON
CAST IRON
420J2 STAINLESS
304 STAINLESS
304 STAINLESS
—
—
—
—
RUBBER (NBR)
RUBBER (NBR)
ASTM, AISI
CODE
A48 Class 30
AISI304
AISI304
A283 Grade D
A48 Class 30
A48 Class 30
A48 Class 30
AISI420
AISI304
AISI304
NO. FOR
1 UNIT
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
1
1
1
120
1
174
120
5
200
Motors are purchased as a complete unit
†: Recommended spare parts
