Ebara Submersible Single Channel Sewage Pumps
DMLEU
Operating, Installation and Maintenance
Ebara
Fluid Handling
www.pumpsebara.com
12
(803) 327-5005 • (803) 327-5097
(fax)
rev. 01/13
80DMLE62.2
PART
NO.
909-2
909-1
907
904
876
849-2
849-1
830
817
816
814
811-2
811-1
802
801
275
211
193
174
135-2
135-1
PART NAMe
eLeCTRODe HOLDeR
eLeCTRODe
BeARING COVeR
LIFTING HANGeR
AUTO CUT
BALL BeARING
BALL BeARING
SHAFT
OPPOSITe SIDe BRACkeT
POWeR SIDe BRACkeT
MOTOR FRAMe
SUBMeRSIBLe CABLe
SUBMeRSIBLe CABLe
STATOR
ROTOR
IMPeLLeR BOLT
AIR VeNT VALVe
OIL PLUG
DISCHARGe PIPe
WASHeR
WASHeR
MATeRIAL
PVC
SUS304
SPCC
SS400
—
—
—
SUS403
FC200
FC200
FC200
—
—
—
—
SUS304
C3604
SUS304
FC200
SUS304
SUS304
NO. FOR
1 UNIT
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
1
PART
NO.
120-7
120-6
120-5
120-4
120-3
120-2
120-1
117-2
117-1
115-4
115-3
115-2
115-1
111
107
080
039
021
016
001
PART NAMe
BOLT
BOLT
BOLT
BOLT
BOLT
BOLT
BOLT
SeAL WASHeR
FLANGe GASkeT
O-RING
O-RING
O-RING
O-RING
MeCHANICAL SeAL
WeARING RING
BUSHING
key
IMPeLLeR
MeCHANICAL SeAL COVeR
CASING
MATeRIAL
SUS304
SUS304
SUS304
SUS304
SUS304
SUS304
SUS304
NBR/304
—
NBR
NBR
NBR
NBR
—
CAC406
SS400
SUS420J2
FC200
FC200
FC200
NO. FOR
1 UNIT
4
3
2
4
4
8
4
1
1
1
1
1
1
1
1
1
1
1
1
1
811
1
811
2
120
4
115
4
849
2
115
3
120
2
849
1
120
5
876
904
817
814
111
016
001
021
080
816
802
801
830
174
211
039
275
120
3
120
1
115
2
115
1
107
117
1
120
7
135
2
135
1
907 120
6
193 117
2
909
1
909
2
