Panel Description

1.7.1 Rear Panel

1 2

3 4

5 6

1. DIP Switches (details below)

2. HDMI Input 1

3. HDMI Input 2

4. HDMI Output over RJ45 (1 – 4)

5. USB: For Internal Use Only

6. Power Jack

1.8

IR Control

Function Key

Function Description

ON/OFF

Turn Output Port On/Off

F1

Select Source 1

F2

Select Source 2

F3

Mute the Sound
