Section 2: Specifications
Item Description
Units HDMI-C5SP-4
Unit Description HDMI 1.3 Transmitter / Splitter over CAT5 / CAT6
HDMI Compliance HDMI 1.3c
HDCP Compliance Yes
Video Bandwidth Single Link 225 MHz (6.75Gbps)
Supported Resolutions 480i / 480p / 720p / 1080i / 1080p60
Resolution and Distance
Full HD: (1080p) ~ 40meter (130feet) (CAT5e) / 50meter (165feet) (CAT6)
HD: (720p/1080i) ~ 50meter (165feet) (CAT5e) / 60meter (200feet) (CAT6)
Audio Support Surround Sound (up to 7.1 Ch) or Stereo Digital Audio
Equalization -
Input TMDS Signal 1.2 Volts (peak-to-peak)
Input DDC Signal 5 Volts (peak-to-peak, TTL)
ESD Protection
- Human body model — ±15kV (air-gap discharge) & ±8kV (contact discharge)
- Core chipset — ±8kV
Input 2 x HDMI
Output 4 x Rj45
HDMI Connector Type A (19 pin female)
RJ45 Connector WE/SS 8P8C with 2 LED indicators
Dimensions (L x W x H) 8.5” x 3.3” x 1.6”
Power Supply 5V 4A DC
Power Consumption 10 Watt (max)
Environmental
Operating Temperature 32˚ ~ 104˚F (0˚ to 40˚C)
Storage Temperature -4˚ ~ 140˚F (-20˚ ~ 60˚C)
Relative Humidity 20~90% RH (no condensation)
