TH/III
InsTallaTIon
/
operaTIon
/
servIce manual pg
. 7
S I T E I N S T A L L A T I O N
I N S T A L L A T I O N
1200-TH/III
75-3/4" (1924mm) with 5" (127mm) Casters
*
22-9/16" (573mm)
68-13/16" (1747mm)
7" (177mm
)
23-1/2" (596mm)
25-1/16" (636mm)
with optional bumper
34-1/2" (876mm)
with optional bumper
24-1/8" (613mm)
32-1/4" (819mm)
15-1/4"
(387mm)
72-15/16" (1852mm) to Electrical Connectio
n
51-5/8" (1310mm
)
53-5/8" (1361mm
)
with optional bumpe
r
*74-3/8" (1889mm) - with optional 3-1/2" (89mm) casters
*75-3/4" (1924mm) approx. - with optional 6" (152mm) legs
72-3/4" (1847mm
)
Pass-Through
Design
Electrical
Connection
(Pass-Through)
WEIGHT
net : 402 lb (182 kg) est
.
ship : 432 lb (196 kg)
PRODUCT\PAN CAPACITY ( per coMpartMeNt )
120 lb (54 kg)
maximum
voluMe MaxiMuM
: 60
quarts
(76
liters
)
