Page 6
6
AUDIO FUNCTION
LINE IN JACK
The
S1297 panel has one ¼” jack labeled LINE IN. The LINE IN receives an external audio signal from any equipment the plug’s
cable is attached to.
INPUTS
INDICATOR LED′s
LED’s starting from the left side;
#1 - POWER STATUS INDICATOR: LED turns green when
power is turned on.
#2 - BATTERY STATUS LED INDICATOR: LED is green
when battery voltage is sufficient for operation.
#3 - Not Used
#4 - WIRELESS MICROPHONE POWER INDICATOR LED
is yellow when power is turned on.
VOLUME
This
VOLUME CONTROL adjusts the sound level of this speaker. If the sound is distorted, reduce the volume level, if it is still
distorted, reduce the level of the source at
the
SW915 or other input device.
#1 POWER
#2 BATTERY
#4 WIRELESS
#3 NOT USED
