Specifications

Prosilica GB

1380

Interface

IEEE 802.3 1000baseT

Resolution

1360 x 1024

Sensor

Sony ICX285

Sensor type

CCD Progressive

Sensor size

Type 2/3

Cell size

6.45 µm

Lens mount

C (adjustable) / CS

Max frame rate at full resolution

30 fps

A/D

14 bit

On-board FIFO

16 MB

Output

Bit depth

8/12 bit

Mono modes

Mono8, Mono12, Mono12Packed

Color modes YUV

YUV411Packed, YUV422Packed, YUV444Packed

Color modes RGB

RGB8Packed, BGR8Packed

Raw modes

BayerRG8, BayerRG12, BayerGR12Packed

General purpose inputs/outputs (GPIOs)

TTL I/Os

1 input, 1 output

Opto-coupled I/Os

1 input, 1 output

RS-232

1

Operating conditions/Dimensions

Operating temperature

0°C ... +70°C

Power requirements (DC)

5-25 VDC*

Power consumption (12 V)

3.5 W

Mass

59 g

Body Dimensions
(L x W x H in mm)

51 x 89 mm (board size - W x L)

Regulations

CE, FCC Class A, RoHS (2011/65/EU)

*5–16 VDC for cameras with SN: 02-22XXA

Download Prosilica GB1380 technical drawing (click here)
