ALLIED Vision Technologies Prosilica GX1910 - Manual (Page 2)

Specifications
Prosilica GX 1910
Interface IEEE 802.3 1000baseT
Resolution 1920 x 1080
Sensor Truesense KAI-02150
Sensor type CCD Progressive
Sensor size Type 2/3
Cell size 5.5 µm
Lens mount C (adjustable)
Max frame rate at full resolution 63 fps
A/D 14 bit
On-board FIFO 128 MB
Output
Bit depth 14 (mono) - 12 (color) bit
Mono modes Mono8, Mono12, Mono12Packed, Mono14
Color modes YUV YUV411Packed
Color modes RGB
RGB8Packed, BGR8Packed, RGBA8Packed, BGRA8Packed,
RGB12Packed
Raw modes BayerGR8, BayerGR12, BayerGR12Packed
General purpose inputs/outputs (GPIOs)
Opto-coupled I/Os 2 inputs, 4 outputs
RS-232 1
Operating conditions/Dimensions
Operating temperature 0°C ... +50°C
Power requirements (DC) 5V - 24V
Power consumption (12 V) 5.6W (1 port) - 6.7W (2 ports)
Mass 269 g
Body Dimensions
(L x W x H in mm)
107.2 x 53.3 x 33 (including connectors, w/o tripod and lens)
Regulations CE, FCC Class A, RoHS (2011/65/EU)
Download Prosilica GX1910 technical drawing (click here)
