Specifications
Prosilica GT 4907
Interface IEEE 802.3 1000baseT
Resolution 4864 x 3232
Sensor Truesense KAI-16070
Sensor type CCD Progressive
Sensor size Type 35 mm
Cell size 7.4 μm
Lens mount F-Mount (M58 optional)
Max frame rate at full resolution 7.6 fps
A/D 14 bit
On-board FIFO 128 MB
Output
Bit depth 14 (mono) - 12 (color) bit
Mono modes Mono8, Mono12, Mono12Packed, Mono14
Color modes YUV YUV411Packed, YUV422Packed
Color modes RGB RGB8Packed, BGR8Packed, RGBA8Packed, BGRA8Packed
Raw modes BayerGR8, BayerGR12, BayerGR12Packed
General purpose inputs/outputs (GPIOs)
TTL I/Os 1 input, 2 outputs
Opto-coupled I/Os 1 input, 2 outputs
RS-232 1
Operating conditions/Dimensions
Operating temperature -20°C ... +50°C
Power requirements (DC) PoE, or 7–25 VDC
Power consumption (12 V) 7.7 W @ 12 VDC
Mass 372 g
Body Dimensions
(L x W x H in mm)
96 x 66 x 53.3 mm including connectors, w/o tripod and lens
Regulations CE, FCC Class A, RoHS (2011/65/EU)
Download the Prosilica GT4907 technical drawing
