ALLIED Vision Technologies Prosilica GT1920 - Manual (Page 2)

Specifications
Prosilica GT 1920
Interface IEEE 802.3 1000baseT
Resolution 1936 x 1456
Sensor Sony ICX674
Sensor type CCD Progressive
Sensor size Type 2/3
Cell size 4.54 µm
Lens mount C (adjustable)
Max frame rate at full resolution 40.7 fps
A/D 14 bit
On-board FIFO 128 MB
Output
Bit depth 14 (mono) - 12 (color) bit
Mono modes Mono8, Mono12, Mono12Packed, Mono14
Color modes YUV YUV411Packed, YUV422Packed
Color modes RGB RGB8Packed, BGR8Packed, RGBA8Packed, BGRA8Packed
Raw modes BayerGR8, BayerGR12, BayerGR12Packed
General purpose inputs/outputs (GPIOs)
TTL I/Os 1 input, 2 outputs
Opto-coupled I/Os 1 input, 2 outputs
RS-232 1
Operating conditions/Dimensions
Operating temperature -20°C ... +60°C
Power requirements (DC) PoE, or 7-25 VDC
Power consumption (12 V) 4.9 W @ 12 VDC
Mass 224 g
Body Dimensions
(L x W x H in mm)
92 x 53.3 x 33 (including connectors, w/o tripod and lens)
Regulations CE, FCC Class A, RoHS (2011/65/EU)
Download Prosilica GT1920 Technical drawing
