Specifications

Prosilica GT

1910

Interface

IEEE 802.3 1000baseT

Resolution

1920 x 1080

Sensor

Truesense KAI-02150

Sensor type

CCD Progressive

Sensor size

Type 2/3

Cell size

5.5 µm

Lens mount

C (adjustable)

Max frame rate at full resolution

57.5 fps

A/D

14 bit

On-board FIFO

128 MB

Output

Bit depth

14 (mono) - 12 (color) bit

Mono modes

Mono8, Mono12, Mono12Packed, Mono14

Color modes YUV

YUV411Packed, YUV422Packed

Color modes RGB

RGB8Packed, BGR8Packed, RGBA8Packed, BGRA8Packed

Raw modes

BayerGR8, BayerGR12, BayerGR12Packed

General purpose inputs/outputs (GPIOs)

TTL I/Os

1 input, 2 outputs

Opto-coupled I/Os

1 input, 2 outputs

RS-232

1

Operating conditions/Dimensions

Operating temperature

-20°C ... +60°C

Power requirements (DC)

PoE, or 7-25 VDC

Power consumption (12 V)

5.1 W @ 12VDC

Mass

224 g

Body Dimensions
(L x W x H in mm)

92 x 53.3 x 33 (including connectors, w/o tripod and lens)

Regulations

CE, FCC Class A, RoHS (2011/65/EU)

Download Prosilica GT1910 Technical drawing

http://www.alliedvisiontec.com/emea/products/cameras/gigabit-ethernet/prosilica-gt/gt1910.html
