Specifications
Prosilica GT 1600
Interface IEEE 802.3 1000baseT
Resolution 1620 x 1220
Sensor Sony ICX274
Sensor type CCD Progressive
Sensor size Type 1/1.8
Cell size 4.4 µm
Lens mount C (adjustable) / CS
Max frame rate at full resolution 25.8 fps
A/D 14 bit
On-board FIFO 128 MB
Output
Bit depth 14 (mono) - 12 (color) bit
Mono modes Mono8, Mono12, Mono12Packed, Mono14
Color modes YUV YUV411Packed, YUV422Packed, YUV444Packed
Color modes RGB RGB8Packed, BGR8Packed
Raw modes BayerRG8, BayerRG12, BayerGR12Packed
General purpose inputs/outputs (GPIOs)
TTL I/Os 1 input, 2 outputs
Opto-coupled I/Os 1 input, 2 outputs
RS-232 1
Operating conditions/Dimensions
Operating temperature -20°C ... +65°C
Power requirements (DC) PoE, or 7-25 VDC
Power consumption (12 V) 3.3 W @ 12 VDC
Mass 211 g
Body Dimensions
(L x W x H in mm)
86 x 53.3 x 33 (including connectors, w/o tripod and lens)
Regulations CE, FCC Class A, RoHS (2011/65/EU)
Download the Prosilica GT1600 technical drawing
