Specifications
Manta G-419 NIR
Interface IEEE 802.3 1000baseT
Resolution 2048 x 2048
Sensor CMOSIS CMV4000
Sensor type CMOS Progressive
Sensor size Type 1
Cell size 5.5 µm
Lens mount C-Mount
Max frame rate at full resolution 28.6 fps
A/D 12 bit
On-board FIFO 128 MB
Output
Bit depth 8-12 bit
Mono modes Mono8, Mono12, Mono12Packed
Raw modes BayerRG8, BayerRG12, BayerRG12Packed
General purpose inputs/outputs (GPIOs)
Opto-coupled I/Os 2 inputs, 2 outputs
RS-232 1
Operating conditions/Dimensions
Operating temperature +5 °C ... +45 °C
Power requirements (DC) 8 V - 30 V
Power consumption (12 V) 3.2 W (PoE) / 2.7 W (non-PoE)
Mass 150 g
Body Dimensions
(L x W x H in mm)
86.4 x 44 x 29 mm incl. connectors
Regulations CE, FCC Class B, RoHS
