Specifications
Manta G-125
Interface IEEE 802.3 1000baseT
Resolution 1292 x 964
Sensor Sony ICX445
Sensor type CCD Progressive
Sensor size Type 1/3
Cell size 3.75 µm
Lens mount C/CS-Mount
Max frame rate at full resolution 30 fps
A/D 14 bit
On-board FIFO 32 MB
Output
Bit depth 8-12 bit
Mono modes Mono8, Mono12, Mono12Packed
Color modes YUV YUV411, YUV422, YUV444
Color modes RGB RGB24, BGR24
Raw modes BayerRG8, BayerGR12, BayerRG12Packed
General purpose inputs/outputs (GPIOs)
Opto-coupled I/Os 2 inputs, 2 outputs
RS-232 1
Operating conditions/Dimensions
Operating temperature +5 °C ... +45 °C
Power requirements (DC) 8 V - 30 V
Power consumption (12 V) <3.6 W
Mass <200 g
Body Dimensions
(L x W x H in mm)
86.4 x 44 x 29 mm incl. connectors
Regulations CE, FCC Class B, RoHS
Download Manta technical drawing (click here)
