Specifications
Guppy F-046
Interface IEEE 1394a - 400 Mb/s, 1 port
Resolution 780 x 582
Sensor Sony ICX415
Sensor type CCD Progressive
Sensor size Type 1/2
Cell size 8.3 µm
Lens mount C
Max frame rate at full resolution 49 fps
A/D 12 bit
Output
Bit depth 8 bit
Mono modes Mono8
Color modes YUV n/a
Color modes RGB n/a
Raw modes Raw8
General purpose inputs/outputs (GPIOs)
TTL I/Os 1 input, 3 outputs
RS-232 1
Operating conditions/Dimensions
Power requirements (DC) 8 V - 36 V
Power consumption (12 V) <2 W
Mass 50 g
Body Dimensions
(L x W x H in mm)
48.2 x 30 x 30 mm incl. connectors
Regulations CE, FCC Class B, RoHS
Download Guppy technical drawing (click here)
