background image

Specifications

Stingray

F-504

Interface

IEEE 1394b - 800 Mb/s, 2 ports, daisy chain, fiber optic (GOF) optional

Resolution

2452 x 2056

Sensor

Sony ICX655

Sensor type

CCD Progressive

Sensor size

Type 2/3

Cell size

3.45 µm

Lens mount

C

Max frame rate at full resolution

9 fps

A/D

14 bit

On-board FIFO

64 MB

Output

Bit depth

8-14 bit

Mono modes

Mono8, Mono12, Mono16

Color modes YUV

YUV411, YUV422

Color modes RGB

RGB8

Raw modes

Raw8, Raw12, Raw16

General purpose inputs/outputs (GPIOs)

Opto-coupled I/Os

2 inputs, 4 outputs

RS-232

1

Operating conditions/Dimensions

Power requirements (DC)

8 V - 36 V

Power consumption (12 V)

<4 W

Mass

92 g

Body Dimensions
(L x W x H in mm)

72.9 x 44 x 29 mm including connectors, w/o tripod and lens

Regulations

CE, FCC Class B, RoHS

Download Stingray technical drawing (click here)

http://www.alliedvisiontec.com/emea/products/cameras/firewire/stingray/f-504bc.html
