Specifications
Guppy PRO F-201
Interface IEEE 1394b - 800 Mb/s, 1 port
Resolution 1624 x 1234
Sensor Sony ICX274
Sensor type CCD Progressive
Sensor size Type 1/1.8
Cell size 4.4 µm
Lens mount C-Mount
Max frame rate at full resolution 14 fps
A/D 12 bit
Output
Bit depth 8-12 bit
Mono modes 8/12/16
Color modes YUV 411/422
Color modes RGB RGB8
Raw modes 8/12/16
General purpose inputs/outputs (GPIOs)
Opto-coupled I/Os 1/3
Operating conditions/Dimensions
Operating temperature +5 °C ... +45 °C
Power requirements (DC) 8 V - 36 V
Power consumption (12 V) <3.5 W
Mass 80 g
Body Dimensions
(L x W x H in mm)
44.8 x 29 x 29 mm incl. connectors
Regulations CE, FCC Class B, RoHS
Download technical drawing (click here)
