Page 10: Model options : unit feature options
10
LN Series Feature String Nomenclature
Model Options
:
Unit Feature Options
GEN
M
J
R
E
V
S
IZ
E
S
E
R
IE
S
M
N
R
E
V
V
L
T
A1
A2
A3
A4
A5
B1
B2
B3
B4
1
2
3A
3B
3C
3D
4A
4B
4C
4D
5A
5B
5C
5D
6
7
8A
8B
8C
9
10A
10B
10C
10D
LN
A
–
140
–
C
–
0
–
3
–
C
A
C
0
E
–
0
0
0
0
:
A
0
– 0 0 0 0 – 0 0 0 0 – 0 0 0 0 – 0 0 – 0 0 0 – 0 – 0 E 0 0 –
0 0 0 0 0 – 0 A 0 0 0 – 0 0 0 0 0 – 0 0 0 0 0 0 – 0 0 0 0 0 – 0 0 0 B
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26A
26B
26C
26D
26E
26F
27
28
29
30
31
32
33
34
35
MODEL OPTIONS
SERIES AND GENERATION
LN
MAJOR REVISION
A
UNIT SIZE
045 = 45 ton Capacity
055 = 55 ton Capacity
060 = 60 ton Capacity
075 = 75 ton Capacity
095 = 95 ton Capacity
105 = 105 ton Capacity
120 = 120 ton Capacity
140 = 140 ton Capacity
SERIES
A = 45-60 ton units
B = 75 ton unit
C = 95-140 ton units
MINOR REVISION
0
VOLTAGE
2 = 230V/3Φ/60Hz
3 = 460V/3Φ/60Hz
4 = 575V/3Φ/60Hz
8 = 208V/3Φ/60Hz
A1: COMPRESSOR STYLE
C = R-410A Tandem VFD Compatible Scroll
Compressor
A2: CONDENSER STYLE
A = Air-Cooled Microchannel Condenser
A3: EVAPORATOR CONFIGURATION
A = Standard Brazed Plate Constant Flow
B = Oversized Brazed Plate Constant Flow
C = Standard Shell & Tube Constant Flow
D = Oversized Shell & Tube Constant Flow
A4: COATING
0 = Standard
E = Polymer E-Coated Condenser Coil
A5: STAGING
0 = Staged Compressors
E = All Circuits with Variable Capacity Compressors
- 2 Circuits
G = Half Circuits with Variable Capacity
Compressors - 2 Circuits
B1: BLANK
0 = Standard
B2: BLANK
0 = Standard
B3: BLANK
0 = Standard
B4: BLANK
0 = Standard
UNIT FEATURE OPTIONS
1: UNIT ORIENTATION
A = Standard Access Left Water Connections
B = Standard Access Right Water Connections
C = Standard Access Bottom Water Connections
2: PUMPING STYLE
0 = No Pumps
B = Constant Flow Primary Pumping System - Large
Pipe Size
D = Variable Flow Primary Pumping System - Large
Pipe Size
