CC Series Feature String Nomenclature
Model Option : Unit Feature Options
G
EN
MJR
EV
UNIT
SIZE
VO
LT
A
G
E
CO
MP
T
YP
E
CIRCUI
TS
1 2 3 4 5 6 7
CC - C - 010 - 3 - D - 2 : B D 0 0 0 A 0
8
BASE MODEL OPTIONS
Series and Generation
CC
Revision
C = Design Sequence
Unit Size
002 = 2 Ton Capacity - Horizontal Discharge
003 = 3 Ton Capacity - Horizontal Discharge
004 = 4 Ton Capacity - Horizontal Discharge
005 = 5 Ton Capacity - Horizontal Discharge
006 = 6 Ton Capacity
007 = 7 Ton Capacity
008 = 8 Ton Capacity
010 = 10 Ton Capacity
014 = 14 Ton Capacity
017 = 17 Ton Capacity
022 = 22 Ton Capacity
025 = 25 Ton Capacity
030 = 30 Ton Capacity
031 = 31 Ton Capacity
034 = 34 Ton Capacity
040 = 40 Ton Capacity
045 = 45 Ton Capacity
050 = 50 Ton Capacity
055 = 55 Ton Capacity
063 = 63 Ton Capacity
Voltage
1 = 230V/1Φ/60Hz
2 = 230V/3Φ/60Hz
3 = 460V/3Φ/60Hz
4 = 575V/3Φ/60Hz
8 = 208V/3Φ/60Hz
9 = 208V/1Φ/60Hz
Compressor Type
0 = No Compressor - Condenser Only
A = R-410A Single Step Scroll Compressor
B = R-410A Two Step Scroll Compressor
C = R-410A Tandem Scroll Compressors
D = R-410A Variable Capacity Scroll Compressor
9 = R-410A Variable Capacity Scroll Compressor -
Each Circuit
Number of Circuits
1 = One Circuit
2 = Two Circuits
4 = Four Circuits
UNIT FEATURE OPTIONS
Feature 1: Ambient Control
0 = Standard - 55°F Ambient
B = Adjustable Fan Cycling - 35°F Ambient
D = Modulating Fan Pressure Control - 35°F
Ambient
F = Flooded Condenser Low Ambient Controls +
Option B
G = Flooded Condenser Low Ambient Controls +
Option D
Feature 2: Refrigeration Options
0 = Standard - Split System Air Conditioner
A = External Hot Gas Bypass
B = Split System Heat Pump
D = Modulating Hot Gas Reheat
F = Options A + D
G = Options B + D
Feature 3: Controls
0 = Standard - Terminal Block with Control
Transformer
A = Suction Pressure Transducer
B = Phase and Brown Out Protection
C = Factory Wired 115V Outlet
D = Options A + B
E = Options A + C
F = Options B + C
G = Options A + B + C
J = Variable Capacity Compressor Integrated
Controls
