22
Table 3 - Predetermined Line Sizes for R-410A CC Condensing Units
Model Circuit
Connection Size Predetermined Line Size
Liquid Suction HGB* HGR** Liquid Suction HGB* HGR**
CC-002 1 3/8'' 3/4'' 3/8'' 1/2'' 3/8'' 3/4'' 3/8'' 1/2''
CC-003 1 3/8'' 3/4'' 1/2'' 1/2'' 3/8'' 3/4'' 1/2'' 1/2''
CC-004 1 1/2'' 7/8'' 1/2'' 5/8'' 1/2'' 7/8'' 1/2'' 5/8”
CC-005 1 1/2'' 7/8'' 1/2'' 5/8'' 1/2'' 7/8'' 1/2'' 5/8''
CC-006 2 3/8'' 7/8'' 3/8'' 1/2'' 3/8'' 7/8'' 3/8'' 1/2''
CC-007 2 1/2'' 7/8'' 1/2'' 1/2'' 1/2'' 7/8'' 1/2'' 1/2''
CC-008 2 1/2'' 7/8'' 1/2'' 5/8'' 1/2'' 7/8'' 1/2'' 5/8''
CC-010 2 1/2'' 7/8'' 1/2'' 5/8'' 1/2'' 7/8'' 1/2'' 5/8''
CC-014 2 5/8'' 1 1/8'' 1/2'' 5/8'' 5/8'' 1 1/8'' 1/2'' 5/8''
CC-017 2 5/8'' 1 1/8'' 5/8'' 3/4'' 5/8'' 1 1/8'' 5/8'' 3/4''
CC-022 2 3/4'' 1 3/8'' 5/8'' 3/4'' 3/4'' 1 3/8'' 5/8'' 3/4''
CC-025 2 3/4'' 1 3/8'' 3/4'' 7/8'' 3/4'' 1 3/8'' 3/4'' 7/8''
CC-030 2 7/8'' 1 3/8'' 3/4'' 7/8'' 7/8'' 1 3/8'' 3/4'' 7/8''
CC-031
2 7/8" 1 3/8'' 3/4'' 7/8'' 7/8" 1 3/8'' 3/4'' 7/8''
4 5/8'' 1 1/8'' 5/8'' 5/8'' 5/8'' 1 1/8'' 5/8'' 5/8''
CC-034
2 7/8" 1 5/8" 3/4'' 7/8'' 7/8" 1 5/8" 3/4'' 7/8''
4 5/8'' 1 1/8'' 5/8'' 3/4'' 5/8'' 1 1/8'' 5/8'' 3/4''
CC-040
2 1 1/8'' 1 5/8" 7/8'' 1 1/8'' 1 1/8'' 1 5/8" 7/8'' 1 1/8''
4 5/8'' 1 3/8'' 5/8'' 3/4'' 5/8'' 1 3/8'' 5/8'' 3/4''
CC-045
2 1 1/8'' 1 5/8" 7/8" 1 1/8'' 1 1/8'' 1 5/8" 7/8" 1 1/8''
4 3/4'' 1 3/8'' 5/8'' 3/4'' 3/4'' 1 3/8'' 5/8'' 3/4''
CC-050
2 1 1/8'' 1 5/8" 7/8" 1 1/8'' 1 1/8'' 1 5/8" 7/8" 1 1/8''
4 3/4'' 1 3/8'' 5/8'' 3/4'' 3/4'' 1 3/8'' 5/8'' 3/4''
CC-055
2 1 1/8'' 1 5/8" 7/8" 1 1/8'' 1 1/8'' 1 5/8" 7/8" 1 1/8''
4 3/4'' 1 3/8'' 3/4'' 7/8'' 3/4'' 1 3/8'' 3/4'' 7/8''
CC-063
2 1 1/8'' 1 5/8" 7/8" 1 1/8'' 1 1/8'' 1 5/8" 7/8" 1 1/8''
4 7/8'' 1 3/8'' 3/4'' 7/8'' 7/8'' 1 3/8'' 3/4'' 7/8''
*Hot Gas Bypass Line
**Hot Gas Reheat Line
