H3/V3 Series Feature String Nomenclature
Model Options
:
Unit Feature Options
GEN
S
IZ
E
OR
E
N
T
M
J
R
E
V
V
L
T
C
OR
R
A1
A2
A3
A4
B1
B2
B3
1A
1B
1C
1D
2
3
4
5A
5B
5C
6A
6B
6C
7
8
9
10
11
12
13
14A
14B
H3 - A R B - 3 - 0 - 1 6 1 C -
1 2 F : A A B B
- 0 C 0 - F T B - 0
G 0 - 0 0 A A A C 0 0 B
A 0 0 0 0 0 0 0 0
15
16
17
18
19
20
21
22
23
11
Model Option B: HEATING
B1: HEATING TYPE
0 = No Heating
1 = Hot Water
3 = Electric Heating
4 = Steam Distributing
B2: HEATING DESIGNATION
0 = No Heating
1 = 1 Row Coil
2 = 2 Row Coil
A = 7 kW (5.3 kW @ 208V)
B = 14 kW (10.5 kW @ 208V)
C = 21 kW (15.8 kW @ 208V)
D = 28 kW (21.0 kW @ 208V)
E = 35 kW (26.3 kW @ 208V)
F = 42 kW (31.5 kW @ 208V)
G = 49 kW (37.0 kW @ 208V)
H = 56 kW (42.0 kW @ 208V)
J = 63 kW (47.3 kW @ 208V)
K = 70 kW (52.5 kW @ 208V)
L = 77 kW (57.8 kW @ 208V)
M = 84 kW (63.0 kW @ 208V)
B3: HEATING STAGES
0 = No Heating
1 = 1 Stage
2 = 2 Stage
3 = 3 Stage
4 = 4 Stage
S = Modulating/SCR Electric
F = Single Serpentine 12 fpi
H = Half Serpentine 12 fpi
Q = Quarter Serpentine 12 fpi
Feature 1: SUPPLY FAN
1A: SUPPLY AIR BLOWER CONFIGURATION
0 = 1 Blower + Premium Eff. Motor
1 = 1 Blower + Premium Eff. Motor + 1 VFD
A = 1 Blower + 1 High Efficiency EC Motor
B = 2 Blowers + 2 High Efficiency EC Motors
1B: SUPPLY AIR BLOWER
1 = 15” Backward Curved Plenum Fan
2 = 15” BC Plenum, 50% Width with Banding
3 = 18.5” Backward Curved Plenum Fan
4 = 18.5” BC Plenum Fan, 70% Width with Banding
5 = 22” Backward Curved Plenum Fan
6 = 24” Backward Curved Plenum Fan
7 = 27” Backward Curved Plenum Fan
8 = 27” BC Plenum Fan, 70% Width with Banding
A = 310 mm Direct Drive BC Plenum Fan
B = 355 mm Direct Drive BC Plenum Fan
C = 450 mm Direct Drive BC Plenum Fan
1C: SUPPLY AIR BLOWER MOTOR
1 = 1 hp - 1760 rpm
2 = 2 hp - 1760 rpm
3 = 3 hp - 1760 rpm
4 = 5 hp - 1760 rpm
5 = 7.5 hp - 1760 rpm
6 = 10 hp - 1760 rpm
B = 1.0 kW (1.34 hp)
C = 1.7 kW (2.28 hp)
D = 3.0 kW (4.02 hp)
E = 5.4 kW (8.00 hp)
1D: SUPPLY BLOWER CONTROL/CONTROL
VENDORS
0 = Standard - Terminal Block
A = Potentiometer Supply Fan Control
B = WattMaster Orion Controls System
C = Field Installed Controls by Others
