Installation Instructions
RFM Series
3
DIMENSIONS
(A)
(B)
RFM-24 SHOWN
MODEL
DIMENSION (A)
DIMENSION (B)
RFM-24
47.36 [1203]
42.00 [1067]
RFM-35
66.61 [1692]
61.25 [1556]
RFM-42
78.86 [2003]
73.50 [1867]
431.8
390.5
15.38
355.6
14.00
489.0
19.25
17.00
0.69
17.5
5.00
127.0
R4.50
114.3
