MWR Installation Instructions
4
DIMENSIONS
Figure 1
24.90
632
20.52
521
3.43
87
B
15°
C
5°
2.5°
Tilted Down Tilted Up Extended Retracted
Tilt Adjustment
Roll Adjustment
15.65
397
16.00
406
1.00
25
7.00
178
2.39
61
8.89
226
2.51
64
18.00
457
3.43
87
ALL MEASUREMENTS ARE IN
THE FOLLOWING FORMAT:
[MILLIMETERS]
INCHES
Mounting Pattern
PRODUCT FEATURES
WEIGHT CAPACITY 125 Lbs
HEIGHT ADJUSTMENT
,-15 / 2.5 / 0
NOTE: CUSTOM INTERFACE BRACKET
NOT SHOWN. THE CUSTOM INTERFACE
BRACKET NEEDED FOR YOUR DISPLAY
WILL ADD BETWEEN 1/2" AND 2" IN DEPTH
AND MAY AFFECT LOCATION OF DISPLAY
ON THE MOUNT.
SEE MSB-XXXX DRAWING ALSO.
