13
42649-01 • 01/30/14 • Hunter Fan Company
Glass Bowl
Bulb
Installing the Glass Bowl
7-1. Partially install two screws in the upper light kit.
7-2. Align the keyholes in the upper light kit ring with
the partially installed screws and rotate to situate
the screws in the narrow ends of the keyholes.
7-3. Install the remaining screw into the upper light kit
ring and securely tighten all three screws.
7-4. Install included 18W CFL bulb.
7-5. Align the tabs in the globe assembly with the tabs
in the light kit ring, then lift the globe assembly
and rotate to engage the tabs. Make sure all tabs
are properly engaged before releasing the globe.
Steps 7-1 - 7-3
Steps 7-4 - 7-5
Screws
7 • Completing Your Installation With a Bowl Light Fixture
Note: In compliance with US federal energy regulations, this
ceiling fan contains a device that restricts its light
output. Exceeding the wattage limit marked on the
MAX wattage sticker affixed to the light socket(s)
may result in fire hazard or improper operation. If
lights do not appear to be operating properly, see the
troubleshooting section.
