Connect the plugs from the upper and
lower switch housings. Make sure to line up
the colored markings on the connectors.
DO NOT ALLOW THE LIGHT KIT TO HANG
BY THE CONNECTORS. THE LIGHT KIT IS
NOT SECURED UNTIL THE STEPS ON
THIS PAGE ARE COMPLETE.
Align the notches in the sides of the lower
switch housing with the switch housing screws
on the upper switch housing. Twist the lower
switch housing clockwise to lock into place.
Light Kit (continued)
Install the third switch housing screw.
Tighten all three screws securely.
Switch
Housing
Screw Notch
Make sure the lower switch housing is securely attached to
the upper switch housing. Failure to properly secure all three
assembly screws could result in the light fixture falling.
15
