Insert the socket ring into the
inner glass as shown, then
carefully place the inner glass
inside the outer glass.
Install the socket ring onto the
socket. Tighten the socket ring
by turning clockwise with the
socket ring tool.
To install each glass assembly,
first remove the socket ring
from the socket, then loosen
the thumbscrews. Set the outer
glass into place. Tighten all
thumbscrews securely.
Outer
Glass Thumbscrew
Socket Ring
Light Kit
Partially install two of the
switch housing screws, found
in the hardware bag.
Want to install your fan without a light kit?
Go to www.HunterFan.com/FAQs and click
“How do I install my fan without the light kit?”
Inner
Glass
Outer
Glass
Socket Ring Tool
Switch
Housing
Screw
Socket Ring
14
