Light Kit
Make sure the lower switch housing is securely attached to
the upper switch housing. Failure to properly secure all three
assembly screws could result in the light fixture falling.
Align the notches in the sides of the lower
switch housing with the upper switch
housing screws. Lift the lower switch housing.
Twist the lower switch housing clockwise to
lock into place. Then thread the fan pull chain
through the hole in the light kit.
Partially install two of the switch housing
screws found in the hardware bag.
Connect the plugs from the upper and lower
switch housings. Make sure to line up the
colored markings on the connectors.
Install the third switch housing screw.
Tighten all three screws securely.
Switch
Housing
Screw
Notch
Switch
Housing
Screw
Want to install your fan without a light kit?
Go to www.HunterFan.com/FAQs and click
“How do I install my fan without the light kit?”
