Motor overload protector, Lint filter – Alliance Laundry Systems DRY683C User Manual
Page 14
Use and Care
506125
12
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Motor Overload Protector
The dryer’s motor overload protector stops the motor
automatically in the event of an overload. After
cooling, the overload protector will reset itself. Dryer
can be restarted by pushing the timer knob in. If
overload protector cycles again, remove the dryer from
use and call the service person to correct the problem.
Lint Filter
The lint filter is located at the front of the dryer in the
lower part of the door opening.
CLEAN THE LINT FILTER BEFORE DRYING
EACH LOAD. Remove lint filter cover, clean lint filter
and replace cover. Annually remove lint filter and
screw to vacuum the duct under it.
Figure 3
DRY694N
1
Lint Filter
DRY694N
1
