Pc 5150, Pc 8120, Inch touch panel pc – Acnodes PC 8120 User Manual
Page 4: Inch core 2 duo touch panel pc
© Copyright 2009 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes’ web site at
PC 5150
15-inch touch panel PC
661 Brea Canyon Rd., Suite 3
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218, www.acnodes.com
4
PC 8120
12-inch Core 2 Duo touch panel PC
Add-on Card Installation
The PC 8120 provides a riser card for PCI slots
expansion. The riser card assemble can accomodate both
half-size expansion cards. To install the riser card, refer to
the following figure and instructions below:
Step 1: Remove the rear chassis.
Step 2: Remove the riser card fix kit.
Step 3: Remove plates.
Step 4: Insert the add-on card in the socket firmly
until it is completely sealed.
