ABTI-GM1
2
INSTALLING THE ABTI-GM1 WITH THE MOTOROLA IHF1000
Note: 8-Way to 8-Way connector harness is used in this application.
NOTE: The ISO to 8 way connector harness will NOT be used in this application.
INSTALLATION PROCEDURE
1) Disconnect the vehicle battery.
2) Remove the radio from the dashboard, and disconnect any cables connected to the radio.
UNP
LUG
EX
IST
ING
UNP
LUG
EXI
STIN
G
FROM CAR
FROM CAR
24 p
in p
lug
12 p
in p
lug
INSTALLATION COMPONENTS
1) ABTI-GM1 interface
2) ABTI-GM1“T” harness
3) 8-Way connector to 8-Way connector harness
4) ISO to 8-way connector harness
TOOLS REQUIRED
1) Tools to remove the OEM radio
2) Wire ties
