Axxess Interface OESWC-LAN11-RF - Manual

© COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
1-800-221-0932 axxessinterface.com
INSTALLATION INSTRUCTIONS FOR PART OESWC-LAN11-RF
The OESWC-LAN11-RF is designed to allow you to add steering
wheel control options to 2006 and up GM LAN11 vehicles. The RF
controlled OESWC-LAN11-RF will allow the customer to adjust their
radio without taking their eyes off the road. The OESWC-LAN11-RF
will come preprogrammed with your most popular features, volume up,
volume down, seek up, seek down, and source. But with the option of
remapping the buttons to fi t every customer needs, this makes this a
must have interfaces that the Axxess line offers.
OESWC-LAN11-RF
INTERFACE COMPONENTS
• A) OESWC Transmitter • B) OESWC Interface • C) Center Keypad
• D) Trim Ring • E) Strap Cover • F) Vehicle T-Harness
A B C D
E
F
TOOLS REQUIRED FOR INSTALLATION
•Cutting Tool •Tape •Crimping Tool
•Connectors (I.E. butt-connectors, bell caps, ECT…)
IGNITIO
N
TERMINALS
WIRE CUTTER M 3.5
M 2.6
M 3
M 5
M 4
IS O
6 2.5 1.5
