Installation manual
Rear panel features
Front panel features
1. PS/2 keyboard port ( )
2. PS/2 mouse port ( )
3. VGA port (
)
4. Parallel port ( )
5. USB 2.0 ports ( ) (some models may
have four rear USB 2.0 ports)
6. LAN (RJ-45) port ( )
7. One of the following ports:
• E-SATA port ( )
• Serial (COM1) port ( )
• DVI port ( )
• Optical S/PDIF Out port ( )
• Coaxial S/PDIF Out port ( )
8. IEEE 1394a port ( ) (some models
only)
1
2
8
6
5
7
3
4
1
2
3
4
5
6
8
7
1. 5.25-inch drive
bay cover
2. 3.5-inch drive bay
cover
3. Headphone port
4. Microphone port
5. USB 2.0 ports*
6. HDD LED
7. Power button
8. Reset button
NOTE: The rear panel ports and their locations
may vary, depending on the model of your
system. For detailed descriptions, refer to the
system User Guide.
7
8
1 2
4
3
5 6
NOTE: *Some models
may have two additional
USB 2.0 ports and/or one
IEEE 1394a port.
